Main FamilyMAX
Device System Gates1250
Maximum Number of User I/Os66
Number of Logic Blocks/Elements4
Number of Macro Cells64
Product Terms32
Program Memory TypeEEPROM
Family NameMAX 3000A
In System ProgrammabilityYes
Maximum Internal Frequency (MHz)125
Maximum Propagation Delay Time (ns)10
Minimum Operating Supply Voltage (V)3
Typical Operating Supply Voltage (V)3.3
Maximum Operating Supply Voltage (V)3.6
Minimum Operating Temperature (°C)0
Maximum Operating Temperature (°C)70
MountingSurface Mount
Package Height (mm)1
Package Length (mm)14
Package Width (mm)14
PCB changed100
Standard Package NameQFP
Supplier PackageTQFP
Pin Count100
Lead ShapeGull-wing
